Toshiba DT02ABA200V 2 To with HDD Bag protection
Specifications
| Form Factor | 3.5-inch |
|---|---|
| Interface | SATA 6 Gbit/s |
| Buffer Size | 128 MiB |
| Rotation Speed | 5400 rpm |
| Maximum Sustained Data Rate (Typ.) | 176.4 MiB/s |
| MTTF/AFR | 1,000,000 h / 0.88% |
Features
- Supports up to 32 cameras high-definition streams
- 128 MiB Cache buffer
- Designed for 24×7 operation
- Annual workload rating of 180TB/year
- MTTF of 1M hours
- Industry-standard 3.5-inch form-factor and SATA interface
- Advanced Format 512e Sector Technology
- Drive-Managed SMR (Shingled magnetic recording) Technology
Models
| Capacity | Active Idle Power Consumption (Typ.) | Weight (Max) | Model Number |
|---|---|---|---|
| 6 TB | 2.69 W | 680 g | DT02ABA600V |
| 4 TB | 2.36 W | 650 g | DT02ABA400V |
| 2 TB | 2.08 W | 440 g | DT02ABA200V |
What is SMR Technology?
SMR (Shingled Magnetic Recording) is overwriting part of the previously written track analogous to the shingling of a roof. CMR and SMR each have their Pros and Cons.
Applications
- Surveillance Video Recorder (SVR)
- Network Video Recorders (NVR)
- Entry- and Mid-Range Surveillance NVR (SNVR)
- Super Digital Video Recorder (SDVR)
- Hybrid (analog and IP) SDVR platforms
50 000 CFA
2 en stock
Description
Specifications
| Form Factor | 3.5-inch |
|---|---|
| Interface | SATA 6 Gbit/s |
| Buffer Size | 128 MiB |
| Rotation Speed | 5400 rpm |
| Maximum Sustained Data Rate (Typ.) | 176.4 MiB/s |
| MTTF/AFR | 1,000,000 h / 0.88% |
Features
- Supports up to 32 cameras high-definition streams
- 128 MiB Cache buffer
- Designed for 24×7 operation
- Annual workload rating of 180TB/year
- MTTF of 1M hours
- Industry-standard 3.5-inch form-factor and SATA interface
- Advanced Format 512e Sector Technology
- Drive-Managed SMR (Shingled magnetic recording) Technology
Models
| Capacity | Active Idle Power Consumption (Typ.) | Weight (Max) | Model Number |
|---|---|---|---|
| 6 TB | 2.69 W | 680 g | DT02ABA600V |
| 4 TB | 2.36 W | 650 g | DT02ABA400V |
| 2 TB | 2.08 W | 440 g | DT02ABA200V |
What is SMR Technology?
SMR (Shingled Magnetic Recording) is overwriting part of the previously written track analogous to the shingling of a roof. CMR and SMR each have their Pros and Cons.
Applications
- Surveillance Video Recorder (SVR)
- Network Video Recorders (NVR)
- Entry- and Mid-Range Surveillance NVR (SNVR)
- Super Digital Video Recorder (SDVR)
- Hybrid (analog and IP) SDVR platforms
